Artculating Brush Cutter
The Articulating Skid Steer Brush Cutter Attachment is designed for cutting banks, fence lines, and right of ways. It also is an excellent choice for clearing pond banks and cutting trails. With a reach of 96” when extended horizontally and a vertical reach of sixteen feet or more (depending on the reach height of your machine).
SKU: ABC-13-125A
The Articulating Skid Steer Brush Cutter Attachment is designed for cutting banks, fence lines, and right of ways. It also is an excellent choice for clearing pond banks and cutting trails. With a reach of 96” when extended horizontally and a vertical reach of sixteen feet or more (depending on the reach height of your machine). This brush cutter will also swing to the right 90° and can be used as a side cutter. A range of hydraulic flow of 14-20 gpm is required. Come with In-Cab Universal Electrical Attachment Control Kit .
• Fits Universal Skid Steer Quick Attach
• Clearing pond banks and cutting trails.
• Swing to the right 90° and can be used as a side cutter.
• High torque motor with 3000 3000 psi relief valve.
• Without control box.
|
Num |
Item | Parameter |
|
1 |
Weight |
1100 lbs |
|
2 |
Hydraulic Flow Required |
14-20 gpm |
| 3 | Cutting Blades (AR400 Grade Steel) | 2 Blades |
| 4 | Material Cutting | Up to 5 in dia |
| 5 | Deck Width (Overall) | 48 in |
| 6 | Cutting Width | 42 in |
| 7 | Height at 90° | 56.5 in |
| 8 | Length | 93 in |
| 9 | Forward Reach | 93 in |
| 10 | Vertical Reach (Varies by Loader) | 254 in |
| 11 | Max Swing Degree | 90° |
| 12 | Max Head Curl Degree | 125° |
| 13 | Max Head Tilt Degree | 35° |
