I. Preface
This product is carefully designed and manufactured to provide you with years of reliable service.
Only minimal maintenance ( such as cleaning and lubrication) is required to keep it in top working condition.
Be sure to follow all maintenance procedures and safety precautions in this manual, as well as any safety stickers on the product and any equipment on which accessories are mounted.
This manual is designed to help you do a better,safer job.
Please read this manual carefully and familiarize yourself with its contents.
Do not allow anyone to operate this equipment without reading this manual.
The illustrations and data used in this manual are current at the time of printing (according to information available to us), but we reserve the right to redesign and change attachments as necessary without notice.
Prior to operation the primary responsibility for the safety of this equipment falls on the operator.
Please ensure that only trained personnel who have read and understood this manual operate the equipment.
If you do not understand this manual or the features, please contact your local authorized dealer or the manufacturer for further assistance.
Make this manual available to new owners and new operators for reference.

II. Security statements
Improper installation, operation or maintenance of this equipment can result in serious personal injury or even death.
Before beginning installation, operation or maintenance, operators and maintenance personnel should carefully read this manual and all manuals pertaining to this equipment and the prime mover.
Follow all safety instructions in this manual and the prime mover manual.
Read and understand all safety statements before operating or using this equipment, read all warning labels and safety statements in manuals.
Know and follow all regulations, local laws and other professional guidelines.
Know and follow good working practices when assembling, maintaining, servicing,installing, disassembling, or operating this equipment. Learn about the performance, size of your device before operation.
Visually inspect the equipment prior to start-up and it is strictly forbidden to operate equipment in a abnormal working condition with all safety devices intact.
Check all hardware to ensure tightness.
Ensure that all latches, pins and connections are properly installed and secured.
Remove and replace any damaged or excessively worn parts.
Make sure all safety decals are in place and legible.
Keep warning labels clean and replace them when they are worn or difficult to read.

Item	Parameters		Note
Model	6-36"		-
-	British Parameter	Metric Parameter	-
Total Weight	420 lbs	190 Kg	-
Working Pressure	3000 psi	21 Mpa	-
Overall Width W	45.3 "	1055 mm	-
Height H	26.3 "	670 mm	-
Length L	78.7 "	2000 mm	-
Effective Mowing Depth W1	37.4 "	950 mm	-
Model of Motor	-	BM3Y-315	Rated flow 75L/min,Speed 240r/min,Power 10Kw
Planetary gearbox	-	3T2A	Maximum output torque 2500N.M
Suitable Loader	Skid steer loader		-
